Exploring macOS private frameworks

TL;DR: This article describes a series of approaches for reverse engineering macOS private frameworks

Apple develops a growing amount of frameworks. As an application developer, you are probably familiar with public frameworks such as AppKit and Core Data. These frameworks are well documented, and you will find lots of tutorials and examples at developer.apple.com or in the Xcode developer documentation (at Help -> Developer Documentation):

Exploring AppKit using Xcode Developer Documentation

Apart from public frameworks, macOS ships with over 1000 private frameworks that are used by system services or as dependencies of public frameworks. Due to their private nature, these frameworks are not documented at all.

This article presents a series of non-exclusive approaches for digging into private frameworks, using the Disk Utility built-in application as an example. Whether you are a security researcher or want a deeper understanding of how macOS software works, being able to peek into these private frameworks is a great tool to keep in your tool belt.

The credit from this post goes to Wojciech Reguła, from whom I learnt all of these techniques (and more!)

Approach 1: otool

Xcode comes with a command-line program called otool(1). This is a general-purpose tool for interacting with Mach-O Apple binary files. One of its convenient features is to list the shared libraries a Mach-O executable links to (using the -L option). With it, we can identify the private frameworks that Apple applications or services link to.

The Disk Utility built-in application we will be looking into in this article lives in /System/Applications/Utilities/Disk Utility.app. Following the structure of macOS application bundles and its Info.plist, we can determine its main executable is Contents/MacOS/Disk Utility.

Every private macOS framework resides in /System/Library/PrivateFrameworks, so we can filter otool(1) results by PrivateFrameworks using grep(1):

$ otool -L /System/Applications/Utilities/Disk\ Utility.app/Contents/MacOS/Disk\ Utility | grep PrivateFrameworks
    /System/Library/PrivateFrameworks/Restore.framework/Versions/A/Restore (compatibility version 1.0.0, current version 615.0.0)
    /System/Library/PrivateFrameworks/DiskManagement.framework/Versions/A/DiskManagement (compatibility version 1.0.0, current version 1.0.0)
    /System/Library/PrivateFrameworks/StorageKit.framework/Versions/A/StorageKit (compatibility version 1.0.0, current version 53.0.0)
    /System/Library/PrivateFrameworks/DiskImages.framework/Versions/A/DiskImages (compatibility version 1.0.8, current version 649.0.0)
    /System/Library/PrivateFrameworks/IASUtilities.framework/Versions/A/IASUtilities (compatibility version 1.0.0, current version 119.0.0)
    /System/Library/PrivateFrameworks/LocalAuthenticationRecoveryUI.framework/Versions/A/LocalAuthenticationRecoveryUI (compatibility version 1.0.0, current version 1394.40.33)
    /System/Library/PrivateFrameworks/MobileObliteration.framework/Versions/A/MobileObliteration (compatibility version 1.0.0, current version 1.0.0)
    /System/Library/PrivateFrameworks/LoginUIKit.framework/Versions/A/LoginUIKit (compatibility version 1.0.0, current version 357.1.0)
    /System/Library/PrivateFrameworks/FindMyDeviceUI.framework/Versions/A/FindMyDeviceUI (compatibility version 1.0.0, current version 1.0.0)
    /System/Library/PrivateFrameworks/apfs_boot_mount.framework/Versions/A/apfs_boot_mount (compatibility version 1.0.0, current version 1.0.0)
    /System/Library/PrivateFrameworks/SkyLight.framework/Versions/A/SkyLight (compatibility version 64.0.0, current version 600.0.0)

An interesting private framework we can explore further, out of these 11 results, is /System/Library/PrivateFrameworks/DiskManagement.framework. But how can we learn more about it if it doesn’t come with any documentation?

Approach 2: RuntimeBrowser

RuntimeBrowser is an open-source macOS application that will list every available public and private framework image and generate Objective-C declarations out of them. RuntimeBrowser browser is not available on Homebrew, so you will need to either build it from source (using Xcode) or download the (unsigned) pre-built version from the official GitHub repository.

In the previous section, we identified /System/Library/PrivateFrameworks/DiskManagement.framework as a potentially interesting private framework to explore. Using RuntimeBrowser, we can locate the DiskManagement image, list the classes it declares, choose a potentially interesting one, and explore its Objective-C interface.

Exploring the DMPartitionDisk class using RuntimeBrowser

In the above example, we are inspecting the DMPartitionDisk class, which has interesting Objective-C methods like addPartitionFollowingPartition. If you have SIP (System Integrity Protection) disabled, you can attach LLDB to Disk Utility and add breakpoints on these methods to explore them further.

You can also import the generated interfaces to an Objective-C project that links to the relevant private frameworks and attempt to call these classes yourself. But how can we better understand these methods to know how to we should use them?

Approach 3: Hopper Disassembler

Hopper is a popular disassembler for reverse engineering macOS frameworks. It requires a paid license to enable its full set of features, but the trial is enough for simple cases like the ones in this article.

In the previous sections, we explored the /System/Library/PrivateFrameworks/DiskManagement.framework private framework that the Disk Utility application links to. If you try to open this framework using Hopper, you will realize that while such framework directory exists on the file system, it doesn’t contain the actual library. In fact, the symbolic link at the top-level of the framework bundle is broken:

$ file /System/Library/PrivateFrameworks/DiskManagement.framework/DiskManagement
/System/Library/PrivateFrameworks/DiskManagement.framework/DiskManagement: broken symbolic link to Versions/Current/DiskManagement

Starting from Big Sur, macOS caches all built-in libraries into a single file for startup performance reasons. Instead of shipping each shared library into their respective locations, macOS now maintains a shared cache for each architecture it supports in the /System/Volumes/Preboot/Cryptexes/OS/System/Library/dyld directory. On my system, I have caches for arm64e and x86_64:

$ file /System/Volumes/Preboot/Cryptexes/OS/System/Library/dyld/dyld_shared_cache_arm64e
/System/Volumes/Preboot/Cryptexes/OS/System/Library/dyld/dyld_shared_cache_arm64e: Dyld shared cache version 1 arm64e

$ file /System/Volumes/Preboot/Cryptexes/OS/System/Library/dyld/dyld_shared_cache_x86_64
/System/Volumes/Preboot/Cryptexes/OS/System/Library/dyld/dyld_shared_cache_x86_64: Dyld shared cache version 1 x86_64

When an application launches, dyld (the open-source Apple dynamic linker), will load the required frameworks from the cached location (referred to as the dyld shared cache) without incurring additional I/O. This is great for performance, but not so great for the purposes of reverse engineering.

The good news is that Hopper is capable of inspecting Mach-O binaries directly from within the dyld shared cache. Let’s use the Hopper CLI to open the arm64e shared cache:

$ hopper --executable /System/Volumes/Preboot/Cryptexes/OS/System/Library/dyld/dyld_shared_cache_arm64e

When the Hopper application launches, it will let you browse the cache for the frameworks that you are interested in using its built-in DYLD Shared Cache loader.

Using Hopper to search for DiskManagement in the DYLD Shared Cache

Once we select DiskManagement.framework, we can use Hopper to find the addPartitionFollowingPartition method (using the Labels section) we saw before in RuntimeBrowser, and select the Pseudo-code mode to see a disassembled version of it.

Using Hopper to disassemble a method of DiskManagement

Finally, you can also export an Objective-C header file out of a framework, similar to how RuntimeBrowser does it, by selecting File -> Export Objective-C Header File....

Using Hopper to export the Objective-C headers of DiskManagement

If you want to generate Objective-C headers out of a Mach-O binary from the command-line, a tool worth looking into is class-dump.

Approach 4: dyld-shared-cache-extractor

While Hopper can select frameworks out of the dyld shared cache for individual inspection, often you want to perform searches (or other operations) across the entire set of private frameworks. However, this is inconvenient to do on the shared cache monolith file.

Luckily, there is an open-source tool called dyld-shared-cache-extractor, which as its name implies, can extract the dyld shared cache into individual files. You can install this program using the author’s Homebrew Tap or build it from source (its a single file of C code).

Once you have it, you can run it by passing as arguments the dyld shared cache you want to extract and the output location. For example, I can extract the arm64e shared cache into $HOME/Projects/dyld-cache-arm64e as follows:

$ dyld-shared-cache-extractor \
  /System/Volumes/Preboot/Cryptexes/OS/System/Library/dyld/dyld_shared_cache_arm64e \
  $HOME/Projects/dyld-cache-arm64e

After a few seconds, your output directory will be populated with every entry of the shared cache, including DiskManagement.framework:

$ file ~/Projects/dyld-cache-arm64e/System/Library/PrivateFrameworks/DiskManagement.framework/Versions/A/DiskManagement
/Users/jviotti/Projects/dyld-cache-arm64e/System/Library/PrivateFrameworks/DiskManagement.framework/Versions/A/DiskManagement: Mach-O 64-bit dynamically linked shared library arm64e

On my system, the arm64e extracted shared cache is 3.5 GB and contains 1535 private frameworks:

$ du -sh ~/Projects/dyld-cache-arm64e
3.5G    /Users/jviotti/Projects/dyld-cache-arm64e

$ ls -1 ~/Projects/dyld-cache-arm64e/System/Library/PrivateFrameworks | wc -l
    1534

Now you can more conveniently open the framework you want to explore in Hopper, but you can also perform searches across the entire cache using grep(1). For example, we can find every private framework that mentions the FileVault disk encryption service as follows:

$ grep --recursive FileVault ~/Projects/dyld-cache-arm64e/System/Library/PrivateFrameworks
Binary file System/Library/PrivateFrameworks/ConfigurationEngineModel.framework/Versions/A/ConfigurationEngineModel matches
Binary file System/Library/PrivateFrameworks/DiskManagement.framework/Versions/A/DiskManagement matches
Binary file System/Library/PrivateFrameworks/Install.framework/Versions/A/Install matches
Binary file System/Library/PrivateFrameworks/Install.framework/Frameworks/DistributionKit.framework/Versions/A/DistributionKit matches
Binary file System/Library/PrivateFrameworks/ConfigurationProfiles.framework/Versions/A/ConfigurationProfiles matches
Binary file System/Library/PrivateFrameworks/CoreUtilsExtras.framework/Versions/A/CoreUtilsExtras matches
Binary file System/Library/PrivateFrameworks/DistributedEvaluation.framework/Versions/A/DistributedEvaluation matches
Binary file System/Library/PrivateFrameworks/LoginUIKit.framework/Versions/A/LoginUIKit matches
Binary file System/Library/PrivateFrameworks/StoreFoundation.framework/Versions/A/StoreFoundation matches
Binary file System/Library/PrivateFrameworks/SpotlightServices.framework/Versions/A/SpotlightServices matches
Binary file System/Library/PrivateFrameworks/SystemMigration.framework/Versions/A/SystemMigration matches
Binary file System/Library/PrivateFrameworks/CoreServicesInternal.framework/Versions/A/CoreServicesInternal matches
Binary file System/Library/PrivateFrameworks/APFS.framework/Versions/A/APFS matches
Binary file System/Library/PrivateFrameworks/SetupAssistantSupport.framework/Versions/A/SetupAssistantSupport matches
Binary file System/Library/PrivateFrameworks/QuickLookIosmac.framework/Versions/A/QuickLookIosmac matches
Binary file System/Library/PrivateFrameworks/SystemAdministration.framework/Versions/A/SystemAdministration matches
Binary file System/Library/PrivateFrameworks/RemoteManagementModel.framework/Versions/A/RemoteManagementModel matches
Binary file System/Library/PrivateFrameworks/FinderKit.framework/Versions/A/FinderKit matches
Binary file System/Library/PrivateFrameworks/OSUpdate.framework/Versions/A/OSUpdate matches
Binary file System/Library/PrivateFrameworks/QuickLookThumbnailingDaemon.framework/Versions/A/QuickLookThumbnailingDaemon matches
Binary file System/Library/PrivateFrameworks/DeviceManagementTools.framework/Versions/A/DeviceManagementTools matches

As you would expect, DiskManagement.framework appears within the occurrences (its the second result).

Approach 5: dylibtree

dylibtree is an open-source third-party utility (from the same author as dyld-shared-cache-extractor) to get a tree-view of the frameworks used by the application. Similar to dyld-shared-cache-extractor, you can install this program using the author’s Homebrew Tap or build it from source.

This tool relies on the dyld shared cache file we saw on previous sections, and it is convenient if want to better understand the dependency chain of applications and their frameworks without having to scan one by one using otool(1).

For example, you can list the dependencies of DiskManagement.framework up to 3 levels deep using the following command:

$ dylibtree --depth 3 \
  --shared-cache-path /System/Volumes/Preboot/Cryptexes/OS/System/Library/dyld/dyld_shared_cache_arm64e \
  ~/Projects/dyld-cache-arm64e/System/Library/PrivateFrameworks/DiskManagement.framework/Versions/A/DiskManagement
/Users/jviotti/Projects/dyld-cache-arm64e/System/Library/PrivateFrameworks/DiskManagement.framework/Versions/A/DiskManagement:
  /System/Library/PrivateFrameworks/DiskManagement.framework/Versions/A/DiskManagement:
    /usr/lib/libcsfde.dylib:
      /System/Library/Frameworks/CoreFoundation.framework/Versions/A/CoreFoundation:
      /System/Library/PrivateFrameworks/ProtectedCloudStorage.framework/Versions/A/ProtectedCloudStorage:
      /usr/lib/libCoreStorage.dylib:
      /System/Library/Frameworks/IOKit.framework/Versions/A/IOKit:
      /System/Library/Frameworks/CoreServices.framework/Versions/A/CoreServices:
      /System/Library/Frameworks/SystemConfiguration.framework/Versions/A/SystemConfiguration:
      /System/Library/Frameworks/Security.framework/Versions/A/Security:
      /System/Library/PrivateFrameworks/EFILogin.framework/Versions/A/EFILogin:
      /usr/lib/libc++.1.dylib:
      /usr/lib/libSystem.B.dylib:
      /System/Library/Frameworks/CFNetwork.framework/Versions/A/CFNetwork:
    /usr/lib/libCoreStorage.dylib
    /System/Library/Frameworks/IOKit.framework/Versions/A/IOKit
    /System/Library/Frameworks/Security.framework/Versions/A/Security
    /System/Library/PrivateFrameworks/MediaKit.framework/Versions/A/MediaKit:
      /System/Library/PrivateFrameworks/APFS.framework/Versions/A/APFS:
      /System/Library/Frameworks/IOKit.framework/Versions/A/IOKit
      /System/Library/Frameworks/CoreFoundation.framework/Versions/A/CoreFoundation
      /usr/lib/libz.1.dylib:
      /usr/lib/libSystem.B.dylib
    /System/Library/Frameworks/DiskArbitration.framework/Versions/A/DiskArbitration:
      /System/Library/Frameworks/CoreFoundation.framework/Versions/A/CoreFoundation
      /System/Library/Frameworks/IOKit.framework/Versions/A/IOKit
      /System/Library/Frameworks/Security.framework/Versions/A/Security
      /usr/lib/libSystem.B.dylib
    /System/Library/Frameworks/DiscRecording.framework/Versions/A/DiscRecording:
      /usr/lib/libz.1.dylib
      /usr/lib/libobjc.A.dylib:
      /System/Library/Frameworks/CoreFoundation.framework/Versions/A/CoreFoundation
      /System/Library/Frameworks/CoreServices.framework/Versions/A/CoreServices
      /System/Library/Frameworks/DiskArbitration.framework/Versions/A/DiskArbitration
      /System/Library/Frameworks/Foundation.framework/Versions/C/Foundation:
      /System/Library/Frameworks/IOKit.framework/Versions/A/IOKit
      /System/Library/Frameworks/Security.framework/Versions/A/Security
      /System/Library/Frameworks/AudioToolbox.framework/Versions/A/AudioToolbox:
      /usr/lib/libc++.1.dylib
      /usr/lib/libSystem.B.dylib
      /System/Library/Frameworks/CFNetwork.framework/Versions/A/CFNetwork
    /System/Library/PrivateFrameworks/CoreAnalytics.framework/Versions/A/CoreAnalytics:
      /System/Library/PrivateFrameworks/AppleSauce.framework/Versions/A/AppleSauce:
      /System/Library/Frameworks/Foundation.framework/Versions/C/Foundation
      /usr/lib/libobjc.A.dylib
      /usr/lib/libc++.1.dylib
      /usr/lib/libSystem.B.dylib
      /System/Library/Frameworks/CoreFoundation.framework/Versions/A/CoreFoundation
    /System/Library/PrivateFrameworks/APFS.framework/Versions/A/APFS
    /System/Library/Frameworks/Foundation.framework/Versions/C/Foundation
    /usr/lib/libobjc.A.dylib
    /usr/lib/libSystem.B.dylib
    /System/Library/Frameworks/CoreFoundation.framework/Versions/A/CoreFoundation
  /usr/lib/libcsfde.dylib
  /usr/lib/libCoreStorage.dylib
  /System/Library/Frameworks/IOKit.framework/Versions/A/IOKit
  /System/Library/Frameworks/Security.framework/Versions/A/Security
  /System/Library/PrivateFrameworks/MediaKit.framework/Versions/A/MediaKit
  /System/Library/Frameworks/DiskArbitration.framework/Versions/A/DiskArbitration
  /System/Library/Frameworks/DiscRecording.framework/Versions/A/DiscRecording
  /System/Library/PrivateFrameworks/CoreAnalytics.framework/Versions/A/CoreAnalytics
  /System/Library/PrivateFrameworks/APFS.framework/Versions/A/APFS
  /System/Library/Frameworks/Foundation.framework/Versions/C/Foundation
  /usr/lib/libobjc.A.dylib
  /usr/lib/libSystem.B.dylib
  /System/Library/Frameworks/CoreFoundation.framework/Versions/A/CoreFoundation

As an engineer working on macOS, you hopefully find these approaches useful!
